VIS Hydraulics RVB0.M16
A screw-in, cartridge style, direct acting, poppet type, normally closed hydraulic relief valve. It’s typically used to protect hydrauliccomponents from pressure transients. When the pressure at the Inlet (1) reaches the valve setting, the valve starts to open to tank(2) providing a limited pressure rise. The reduced dimensions and the excellent response time make this valve ideally suited for pilotcircuits. Hysteresis is also extremely low.
Product Attributes
- WeightKg
- 0.05
- Installation torqueNm
- 35 - 40
- Filtration
- 20/18/15 iso 4406 (maximum filtration admitted)
- Orientation
- No restrictions
- Oil Testing Conditions
- ISO VG 46 cSt
- Fluid
- Mineral - based or synthetics with lubricating properties
- WeightKg
Pressure Attributes
- Max PressureBar
- 450.0
- Tightening Torque
- 6.5 - 8.5
- Max PressureBar
Flow Attributes
- Max Flowl/min
- 1.5
- ViscositiescSt
- 7.4 - 420
- Max Flowl/min
| SKU | Price | Add to shopping cart | Favorites | |
|---|---|---|---|---|
| RVB0.M16.0B.000 | on request | Delivery time: 8-10 weeks | ||
| RVB0.M16.0G.000 | on request | Delivery time: 8-10 weeks | ||
| RVB0.M16.0N.000 | on request | Delivery time: 8-10 weeks | ||
| RVB0.M16.0Y.000 | on request | Delivery time: 8-10 weeks |
