Winner Hydraulics CO-08W-X-Y-Z
Winner Hydraulics CO-08W-X-Y-Z
Product Attributes
- WeightKg
- 0.06
- Installation torqueNm
- 25 - 35
- Cavity Tooling
- 08W-3
- WeightKg
Pressure Attributes
- Max PressureBar
- 240.0
- Max PressureBar
Flow Attributes
- Rated Flowl/min
- 30.0
- Rated Flowl/min
| SKU | Options (Z) | Operation (X) | Springs (Y) | Price | Add to shopping cart | Favorites | |
|---|---|---|---|---|---|---|---|
| CO-08W-30-41-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-41-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-69-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 6.9 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-69-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 6.9 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-82-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 8.2 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-33-17-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 3:1 | 1.7 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-33-41-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 3:1 | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-33-62-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 3:1 | 6.2 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-103-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 10.3 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-103-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 10.3 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-138-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 13.8 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-138-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 13.8 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-176-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 17.6 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-176-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 17.6 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-17-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 1.7 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-17-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 1.7 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-41-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-41-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-69-L | Leakproof hex. socket screw. | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 2:1 (Check Spring Bias) (Min. 4.1 bar) | 6.9 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-69-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 6.9 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3A-82-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 Sealed Pilot Piston (Check Spring Bias) (Min. 4.1 bar) | 8.2 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3C-17-N | Not Adjustable | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 3:1 (Check Spring Bias) (Min. 4.8 bar) | 1.7 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3C-41-N | Not Adjustable | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 3:1 (Check Spring Bias) (Min. 4.8 bar) | 4.1 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-3C-62-N | Not Adjustable | 2 to 3 (Free Flow) Sealed Pilot Piston Pilot Ratio 3:1 (Check Spring Bias) (Min. 4.8 bar) | 6.2 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-103-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 10.3 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-103-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 10.3 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-138-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 13.8 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-138-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 13.8 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-176-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 17.6 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-176-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 17.6 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-17-L | Leakproof hex. socket screw. | 2 to 3 Free Flow (Pilot to Open) Pilot Ratio 2:1 (Check Spring Bias) Min. 1.7 bar | 1.7 bar | on request | Delivery time: 8-10 weeks | ||
| CO-08W-30-17-N | Not Adjustable | 2 to 3 (Free Flow) Pilot Ratio 2:1 (Check Spring Bias) (Min. 1.7 bar) | 1.7 bar | on request | Delivery time: 8-10 weeks |
