Winner Hydraulics EP-08W-X-Y-Z-05
Winner Hydraulics EP-08W-X-Y-Z-05
Product Attributes
- WeightKg
- 0.13
- Installation torqueNm
- 39 - 51
- Cavity Tooling
- 08W-2
- Mounting Position
- Unrestricted
- Filtrationµm
- 25.0
- Minimum Voltage Required%
- 90.0
- WeightKg
Pressure Attributes
- Max PressureBar
- 350.0
- Max PressureBar
Flow Attributes
- Rated Flowl/min
- 40.0
- Fluids Temperatures°C
- -40 - 120
- Internal Leakagecc/minute
- 0.15
- Rated Flowl/min
| SKU | Structure (X) | Operations (Y) | Options (Z) | Price | Add to shopping cart | Favorites | |
|---|---|---|---|---|---|---|---|
| EP-08W-2A-31-H-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Pull Stype (Hand Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-31-L-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Pull Stype (Cable Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-31-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-31-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-32-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-32-P-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-32-T-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Double Lock | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-1-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-1-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-01-H-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized | Pull Stype (Hand Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-08-N-05 | 2 Ports, 20 Watt. Coil | Normally-Open With Filter No Reverse Flow De-energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-08-P-05 | 2 Ports, 20 Watt. Coil | Normally-Open With Filter No Reverse Flow De-energized | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-08-T-05 | 2 Ports, 20 Watt. Coil | Normally-Open With Filter No Reverse Flow De-energized | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-09-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized Nose-in Side-out Operation | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-09-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized Nose-in Side-out Operation | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-10-N-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized Nose-in Side-out Operation | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-10-P-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized Nose-in Side-out Operation | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-10-T-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized Nose-in Side-out Operation | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-01-L-05 | 2 Ports, 20 Watt. Coil | Normally-Closed No Reverse Flow Energized | Pull Stype (Cable Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-02-N-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-02-P-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-02-T-05 | 2 Ports, 20 Watt. Coil | Normally-Open No Reverse Flow De-energized | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-03-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Reverse Flow Energized Nose-in Side-out Operation | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-03-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Reverse Flow Energized Nose-in Side-out Operation | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-04-N-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-energized Nose-in Side-out Operation | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-04-P-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-energized Nose-in Side-out Operation | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-04-T-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-energized Nose-in Side-out Operation | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-05-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Reverse Flow Energized | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-05-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed Reverse Flow Energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-06-N-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-Energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-06-P-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-Energized | Push Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-06-T-05 | 2 Ports, 20 Watt. Coil | Normally-Open Reverse Flow De-Energized | Push and Twist Style Manual Override | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-07-H-05 | 2 Ports, 20 Watt. Coil | Normally-Closed With Filter No Reverse Flow Energized | Pull Stype (Hand Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-07-L-05 | 2 Ports, 20 Watt. Coil | Normally-Closed With Filter No Reverse Flow Energized | Pull Stype (Cable Operated) | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-07-M-05 | 2 Ports, 20 Watt. Coil | Normally-Closed With Filter No Reverse Flow Energized | Screw-Out Knob Style | €96,98 | Delivery time: 8-10 weeks | ||
| EP-08W-2A-07-N-05 | 2 Ports, 20 Watt. Coil | Normally-Closed With Filter No Reverse Flow Energized | Non-adjustable | €96,98 | Delivery time: 8-10 weeks |
